SWITCH BATTERY TYPE

backup power battery

CYCLIC POWER BATTERY

HIGH POWER BATTERY

ELECTRIC VEHICLE BATTERY

LONGLIFE TELECOM BATTERY

GREEN ENERGY BATTERY

GREEEN ENERGY BATTERY

APPLICATION

Solar Power Storage System
Wind Power Storage System
Hydropower Storage System
Green Energy Storage System

FEATURES

Safe and effective explosion-proof and ventilation design.
Available for side, vertical, or upright installation.
Non-spill able and maintenance free.
UL 1989 certified.
Compliant with the IATA/A67 and IMDG/238 requirements for transportation.
Long life and low self-discharge rate

SWITCH BATTERY SERIES

CWP SERIES

PRODUCTS

BATTERY TYPE	NOMINAL VOLTAGE (V)	NOMINAL CAPACITY (AH)		DIMENSION (MM)				DIMENSION (INCH)				WEIGHT (APPROX.)		PDF	Inquiry
BATTERY TYPE	NOMINAL VOLTAGE (V)	5HR	20HR	L	W	H	HT	L	W	H	HT	KG	LBS	PDF	Inquiry
CWP100-12N	12	85	100	338	170	212	217	13.31	6.69	8.35	8.54	34.5	75.9
CWP200-12N	12	170	200	522	238	219	224	20.55	9.37	8.62	8.82	75	165
WPG200-12AN	12	170	200	522	238	219	224	20.55	9.37	8.62	8.82	63	138.6
