General Purpose

This series is designed as a general-purpose battery with a wide range of applications.

Battery Model	NOMINAL VOLTAGE(V)	NOMINAL CAPACITY(Ah)				DIMENSION				WEIGHT	PDF
Battery Model	NOMINAL VOLTAGE(V)	Watt	5HR	10HR	20HR	L	W	H	HT	WEIGHT	PDF
GF170-8	8		139.4		170	260	183	245	287	28
LGD225-6NE	6		191.3		225	260	180	265	272	30.5

Metric mm/kg
Imperial inch/lbs

Battery Model	NOMINAL VOLTAGE(V)	NOMINAL CAPACITY(Ah)				DIMENSION				WEIGHT	PDF
Battery Model	NOMINAL VOLTAGE(V)	Watt	5HR	10HR	20HR	L	W	H	HT	WEIGHT	PDF
22NF305CNE	12		52.7		62	226	135	207	214	18.7
22NF305CN	12		52.7		62	226	135	207	214	18.7
(copy) KPH110-12N
KPH65-12N	12		55.25		65	260	170	202	207	22.5
KPH75-12U	12		63.75		75	260	170	202	222	24.2
KPH75-12N	12		63.75		75	260	170	202	207	24.2
KPH80-12N	12		68		80	260	170	202	207	24.2
KPH100-12AU	12		85		100	307	168	208	230	29
KPH100-12AN	12		85		100	307	168	208	213	29
KPH110-12N	12		93.5		110	338	170	212	217	31
KPH130-12N	12		110.5		130	352	170	273	278	43
KPH150-12N	12		127.5		150	352	170	273	278	46
WP6-2	2		5.1		6	50	34	100	108	0.396
WP1.2-6	6		1.02		1.2	97	25	52	57	0.289
WPS4-6	6		3.4		4	70	47	102	106	0.745
WP4.5-6	6		3.825		4.5	70	47	102	106	0.82
WP5-6	6		4.25		5	70	47	102	106	0.83
WP7-6S	6		5.95		7	116	50	92	99	1.45
WP7-6	6		5.95		7	151	34	94	100	1.23
WP9-6A	6		7.65		9	98.5	56	118	118	1.7
WP10-6	6		8.5		10	151	50	94	100	1.7
WP12-6S	6		10.2		12	151	50	94	99	1.84
WP13-6	6		11.05		13	108	70	140	140	2.24
WP20-6	6		17		20	157	83	125	125	3.89
WP7-12(28W)T	12	28			7	151	65	94	106	2.19
WP7-12(28W)	12	28			7	151	65	94	102	2.18
WP0.7-12S	12		0.595		0.7	96	25	62	62	0.364
WP0.7-12	12		0.595		0.7	96	25	62	62	0.364
WP1.2-12T	12		1.02		1.2	97	48	50	56	0.58
WP1.2-12	12		1.02		1.2	97	43	53	59	0.55
WP2-12	12		1.7		2	150	20	90	90	0.705
WP2.2-12	12		1.87		2.2	178	34	60	66	0.985
WP2.3-12	12		1.955		2.3	178	34.5	60	66	0.965
WP2.6-12	12		2.21		2.6	178	34.5	60	66	0.965
WP2.9-12TR	12		2.465		2.9	79	56	99	107	1.19
WP2.9-12T	12		2.465		2.9	79	56	99	107	1.19
WP3-12	12		2.55		3	134	67	59.5	65.5	1.3
WP4.5-12	12		3.825		4.5	90	70	101.5	107	1.62
WP5-12SHR	12		4.25		5	90	70	101.5	107	1.93
WP5-12	12		4.25		5	90	70	101.5	107	1.9
WP7.2-12	12		6.12		7.2	151	65	94	102	2.4
WP9-12SHR	12		7.65		9	151	65	94	102	2.7
WP12-12A	12		10.2		12	151	98	93	98	3.6
WP12-12	12		10.2		12	151	98	93	98	4.02
WP18-12U	12		15.3		18	181	76	167	167	6.3
WP18-12N	12		15.3		18	181	76	167	167	6.3
WP18-12I	12		15.3		18	181	76	167	167	6.3
WP18-12	12		15.3		18	181	76	167	167	6.3
WP20-12U	12		17		20	181	76	167	167	5.95
WP20-12N	12		17		20	181	76	167	167	5.95
WP20-12I	12		17		20	181	76	167	167	5.95
WP20-12	12		17		20	181	76	167	167	5.95
WP22-12SN	12		18.7		22	181	77	170	170	7.05
WP22-12NSHR	12		18.7		22	181	77	167	167	6.7
WP22-12ASN	12		18.7		22	181	77	170	180.6	7.05
WP22-12N	12		18.7		22	181	76	167	167	6.9
WP24-12N	12		20.4		24	166	175	125	125	8.1
WP24-12	12		20.4		24	166	175	125	125	8.1
WP26-12TN	12		22.1		26	166	125.5	176	176	8.8
WP26-12N	12		22.1		26	166	175	125	125	9.1
WP26-12	12		22.1		26	166	175	125	125	9.1
WP30-12TN	12		25.5		30	166	125.5	176	176	9.3
WP40-12N	12		34		40	198	166	171	171	13.4
WP40-12	12		34		40	198	166	171	171	13.4
WP45-12N	12		38.25		45	198	166	171	171	13.5
WP45-12	12		38.25		45	198	166	171	171	13.5
WP50-12N	12		42.5		50	199	166	171	171	15
WP50-12	12		42.5		50	199	166	171	171	15
WP55-12N	12		46.75		55	226	135	207	214	17.1
WP55-12	12		46.75		55	226	135	207	229	17.1

Battery Model	NOMINAL VOLTAGE(V)	NOMINAL CAPACITY(Ah)				DIMENSION				WEIGHT	PDF
Battery Model	NOMINAL VOLTAGE(V)	Watt	5HR	10HR	20HR	L	W	H	HT	WEIGHT	PDF
22NF305CNE	12		52.7		62	8.9	5.31	8.15	8.43	41.14
22NF305CN	12		52.7		62	8.9	5.31	8.15	8.43	41.14
(copy) KPH110-12N
KPH65-12N	12		55.25		65	10.24	6.69	7.95	8.15	49.5
KPH75-12U	12		63.75		75	10.24	6.69	7.95	8.74	53.24
KPH75-12N	12		63.75		75	10.24	6.69	7.95	8.15	53.24
KPH80-12N	12		68		80	10.24	6.69	7.95	8.15	53.24
KPH100-12AU	12		85		100	12.09	6.61	8.19	9.06	63.8
KPH100-12AN	12		85		100	12.09	6.61	8.19	8.39	63.8
KPH110-12N	12		93.5		110	13.31	6.69	8.35	8.54	68.2
KPH130-12N	12		110.5		130	13.86	6.69	10.75	10.94	94.6
KPH150-12N	12		127.5		150	13.86	6.69	10.75	10.94	101.2
WP6-2	2		5.1		6	1.97	1.34	3.94	4.25	0.87
WP1.2-6	6		1.02		1.2	3.82	0.98	2.05	2.24	0.64
WPS4-6	6		3.4		4	2.76	1.85	4.02	4.17	1.64
WP4.5-6	6		3.825		4.5	2.76	1.85	4.02	4.17	1.8
WP5-6	6		4.25		5	2.76	1.85	4.02	4.17	1.83
WP7-6S	6		5.95		7	4.57	1.97	3.62	3.9	3.19
WP7-6	6		5.95		7	5.94	1.34	3.7	3.94	2.71
WP9-6A	6		7.65		9	3.88	2.2	4.65	4.65	3.74
WP10-6	6		8.5		10	5.94	1.97	3.7	3.94	3.74
WP12-6S	6		10.2		12	5.94	1.97	3.7	3.9	4.05
WP13-6	6		11.05		13	4.25	2.76	5.51	5.51	4.93
WP20-6	6		17		20	6.18	3.27	4.92	4.92	8.56
WP7-12(28W)T	12	28			7	5.94	2.56	3.7	4.17	4.82
WP7-12(28W)	12	28			7	5.94	2.56	3.7	4.02	4.8
WP0.7-12S	12		0.595		0.7	3.78	0.98	2.44	2.44	0.8
WP0.7-12	12		0.595		0.7	3.78	0.98	2.44	2.44	0.8
WP1.2-12T	12		1.02		1.2	3.82	1.89	1.97	2.2	1.28
WP1.2-12	12		1.02		1.2	3.82	1.69	2.09	2.32	1.21
WP2-12	12		1.7		2	5.91	0.79	3.54	3.54	1.55
WP2.2-12	12		1.87		2.2	7.01	1.34	2.36	2.6	2.17
WP2.3-12	12		1.955		2.3	7.01	1.36	2.36	2.6	2.12
WP2.6-12	12		2.21		2.6	7.01	1.36	2.36	2.6	2.12
WP2.9-12TR	12		2.465		2.9	3.11	2.2	3.9	4.21	2.62
WP2.9-12T	12		2.465		2.9	3.11	2.2	3.9	4.21	2.62
WP3-12	12		2.55		3	5.28	2.64	2.34	2.58	2.86
WP4.5-12	12		3.825		4.5	3.54	2.76	4	4.21	3.56
WP5-12SHR	12		4.25		5	3.54	2.76	4	4.21	4.25
WP5-12	12		4.25		5	3.54	2.76	4	4.21	4.18
WP7.2-12	12		6.12		7.2	5.94	2.56	3.7	4.02	5.28
WP9-12SHR	12		7.65		9	5.94	2.56	3.7	4.02	5.94
WP12-12A	12		10.2		12	5.94	3.86	3.66	3.86	7.92
WP12-12	12		10.2		12	5.94	3.86	3.66	3.86	8.84
WP18-12U	12		15.3		18	7.13	2.99	6.57	6.57	13.86
WP18-12N	12		15.3		18	7.13	2.99	6.57	6.57	13.86
WP18-12I	12		15.3		18	7.13	2.99	6.57	6.57	13.86
WP18-12	12		15.3		18	7.13	2.99	6.57	6.57	13.86
WP20-12U	12		17		20	7.13	2.99	6.57	6.57	13.09
WP20-12N	12		17		20	7.13	2.99	6.57	6.57	13.09
WP20-12I	12		17		20	7.13	2.99	6.57	6.57	13.09
WP20-12	12		17		20	7.13	2.99	6.57	6.57	13.09
WP22-12SN	12		18.7		22	7.13	3.03	6.69	6.69	15.51
WP22-12NSHR	12		18.7		22	7.13	3.03	6.57	6.57	14.74
WP22-12ASN	12		18.7		22	7.13	3.03	6.69	7.11	15.51
WP22-12N	12		18.7		22	7.13	2.99	6.57	6.57	15.18
WP24-12N	12		20.4		24	6.54	6.89	4.92	4.92	17.82
WP24-12	12		20.4		24	6.54	6.89	4.92	4.92	17.82
WP26-12TN	12		22.1		26	6.54	4.94	6.93	6.93	19.36
WP26-12N	12		22.1		26	6.54	6.89	4.92	4.92	20.02
WP26-12	12		22.1		26	6.54	6.89	4.92	4.92	20.02
WP30-12TN	12		25.5		30	6.54	4.94	6.93	6.93	20.46
WP40-12N	12		34		40	7.8	6.54	6.73	6.73	29.48
WP40-12	12		34		40	7.8	6.54	6.73	6.73	29.48
WP45-12N	12		38.25		45	7.8	6.54	6.73	6.73	29.7
WP45-12	12		38.25		45	7.8	6.54	6.73	6.73	29.7
WP50-12N	12		42.5		50	7.83	6.54	6.73	6.73	33
WP50-12	12		42.5		50	7.83	6.54	6.73	6.73	33
WP55-12N	12		46.75		55	8.9	5.31	8.15	8.43	37.62
WP55-12	12		46.75		55	8.9	5.31	8.15	9.02	37.62
